Fully/ Semi automatic full load type testing panel for Induction motors

Range : Up to 1500 Amp.

Inquiry

Semi and Fully Automatic Full Load Testing Panel For All Kind Of Pump

Aarohi introduced a fully/ Semi automatic type testing system for induction motors As per IEC/ IS standards. With help of highly successful water cooled dynamometer testing on electric motors with a wide range of power outputs ensures that your motors is operating at peak efficiency.It accurately places at controllable load on electric motors ranging from 1 HP to 1000 HP.

Specification

Parameter	Description
Range	Up to 1500 Amp.
Enclosure (Panel) type	Table top, ATM , Cupboard
Test covered	Type tests: No load, Locked rotor/ Full load/ Momentary overload/ Temp. rise test & customer specific test (Optional)
Computer interface	Rs 485
Suitable Motor type	1 & 3 phase motors
Data login	Manual by clicking log button on computer system
Software	“ Motor analyser” Clint server based software with user management for all types of motor with realtime data monitoring & production report generation.
Loading device	Water cooled dynamo meter
Protections	MCB/ MCCB for overload protection, Isolation transformer for auxiliary protection.
Output connections	Screw less terminals inside panel
Voltage control	Automatic though motorised dimmer according to master data
Mode of operation	Automatic & manual both provided
Enclosure/ Panel colour	Siemens grey

Application

Test lab at motor manufacturer.
Repairing/ Service centres
Motor testing labs.
Lab. for educational institute.

Feature

FEATURES	BENEFIT
Automatic data logging facility	Minimize human efforts & errors
Model/ Motor wise report generation	Provide production data analytics
Client server-based software	Anyone can access easily it on a network
Operator friendly operation	Increases work efficiency
Aesthetic design of panel	Create a good imprecation on visitors
Software with user management	Avoid unauthorised usage.
