Digital RPM Meter

Range: 9999 RPM

Digital RPM Meter

Digital RPM Meter

“ AAROHI” make Digital RPM meter is very compact & specially designed microprocessor-based instrument to measure RPM of the motor. This unique meter detects RPM through contactless IR sensors / Proxy sensors which increases productivity & avoids breakdown.

Parameter Description
Range 9999 RPM
Display type 4 Digit 0.56” red seven-segment LED Display also LED indication provided for direction.
Least count 1 RPM
Accuracy 0.5 %
Auxiliary supply 230V AC ± 10%
Interface RS 485
Dimensions 96mm x 96mm x 130mm
FEATURES BENEFIT
Class of accuracy: 0.5% Testing according to IS/ IEC standard is possible
Computer interface through RS-485 Data acquisition is very easy
Easy to operate Increases work efficiency
Operate on contactless sensors Increase productivity & reduce physical damage
0.56” seven-segment display Visible from long distance
  • Production line or QA testing of electric devices
  • Motor Industries
  • Generator testing
Request for

Quote

    Instant Online Request for Quote
