Pressure Controller

Range : Up to 100 BAR

Pressure Controller

Pressure Controller

Aarohi introduces pressure controllers which gives rapid response & quickly adjust desired pressure. Because of micro controller based design it provides high accuracy and control stability. pressure controllers are especially suitable to maintain constant pressure in solar pump testing , Submersible/ Open well pump testing & water distribution system.

Parameter

Description

Range

Up to 100 BAR

Display type

4 Digit 0.56” red seven segment

Least count

0.1 Bar

Accuracy

0.5 %

Range selection

Programmable through key board

Out put

1 Relay output

Computer Interface

Rs 485/ 232

Auxiliary supply

230V AC ± 10%

Dimensions

60mm x 160mm x 100mm

FEATURES

BENIFIT

Microcontroller based design

Provides even accuracy for entire range

Class of accuracy: 0.5

Testing according to IS/ IEC standard is possible

Computer interface through RS-485/ Rs-232

Data acquisition is very easy.

Easy to operate

Increases work efficiency

4-20 MA input

Easy to connect any range of transducer.

0.56” seven segment display

Visible from long distance

  • Solar pump testing.
  • Water distribution system.
  • Ceramic industries.
  • Forging industries.
  • Food industries
