Aarohi make Insulation resistance tester / megger enable us to measure electrical leakage in wire, results are very reliable as we shall be passing an electric current through device while we are testing.
The equipment basically uses for verifying the electrical insulation level of any device such as motors, cables, generators, windings, etc.
| Parameter | Description |
| Model | IT4303CZZ |
| Operating Voltage | 500 Vdc |
| Range | 1000 MΩ |
| Conversion time | 2.5 sec. |
| Over- Range indication | “OVER” is displayed |
| Display type | 3 1/2 Digit 0.56” red seven segment |
| Least count | 1 MΩ |
| Operating temp | 0 to 50 deg. Centgrate |
| Relative humidity | 80 % maximum |
| Accuracy | 1 % |
| Dielectric strength | 3.5 KV @ 50Hz for 1 min. between Input Terminals & Case |
| Computer Interface | Rs 485 |
| Auxiliary supply | 12 V dc |
| Dimensions | 60mm x 160mm x 100mm |
|
FEATURES |
BENEFIT |
|
Class of accuracy: 5% |
Testing according to IS/ IEC standard is possible |
|
Computer interface through RS-485 |
Data acquisition is very easy. |
|
Easy to operate |
Increases work efficiency |
|
Low weight |
Easy to carry |
|
4 Digit Red seven-segment display |
Visible from long distance |
- HV transformers
- Used in motors, transformers, and cables.
- Railways
- Power generation
- Quality Testing Companies
- Solar generation
- Industrial companies.
- circuit breakers
